LATICRETE® Hydro Ban®

A versatile, self-curing waterproofing and crack isolation membrane for seamless protection.

Thumbnail
LATICRETE® Hydro Ban®


LATICRETE® Hydro Ban®

A versatile, self-curing waterproofing and crack isolation membrane for seamless protection.

Colour: Green

SKU:

Colour:
Green

SKU:


Compliance:

certificate logo

ANSI: A 118.12

certificate logo

ANSI: A 118.10

certificate logo

ETAG: 022

Product Overview

LATICRETE® Hydro Ban® is a revolutionary thin, load-bearing concrete waterproofing membrane. This single-component, self-curing liquid rubber polymer forms a flexible, seamless barrier without the need for fabric in the field, coves or corners.

It bonds directly to a wide variety of substrates, making it the ideal choice for reliable and efficient waterproofing. Transform your surfaces with LATICRETE® Hydro Ban® and enjoy ultimate protection with ease.

Waterproofing
Waterproofing

Features & Benefits

blue backgtound

1

Simple & Quick Application

The single component formula simplifies the waterproofing process

blue backgtound

2

No fabric required

No fabric is needed for joints up to 3 mm, streamlining installation

blue backgtound

3

Versatile Bonding

Adheres directly to copper, steel and PVC plumbing fixtures

blue backgtound

4

Quick Drying

Fast drying time allows for flood testing within 24 hours, speeding up project completion

Product Details

Specifications

Packaging-
20 ltr pail
Coverage-
Approx. 225-250 sq. ft. per 20 ltr pail
Colour-
Green
Compliance -
ANSI: A 118.12
ANSI: A 118.10
ETAG: 022
VOC: Very Low

Substrates Details

*Interior applications only.

**If skim coated with a LATICRETE® Latex Mortar.

***Consult cement backer board manufacturer for specific installation recommendations and to verify acceptability for exterior use.

Substrates

Concrete

Concrete

Brick Masonry

Brick Masonry

Cement Mortar Beds

Cement Mortar Beds

Cement Plaster

Cement Plaster

Gypsum Wall Board

Gypsum Wall Board*

Cement Terrazzo

Cement Terrazzo**

Cement Backer Board

Cement Backer Board***

Ceramic Tile

Ceramic Tile

Substrates Details

*Interior applications only.

**If skim coated with a LATICRETE® Latex Mortar.

***Consult cement backer board manufacturer for specific installation recommendations and to verify acceptability for exterior use.

FAQs

LATICRETE® Hydro Ban® is latex based under tile water proofing membrane which has high flexibility, crack bridging ability and high load bearing capacity

Available in 20 Kg Pail

No water mixing is allowed with Hydro Ban®. It is a single component semi liquid paste which is used directly using a roller or a brush. It can also be applied using a spray machine.

The following preparation must be done before application of Hydro Ban®:

  • Clean the surface of the substrate free of dust and debris with wet cloth or sponge.
  • Don’t allow water to stand on the surface prior to using Hydro Ban®. Allow the surface to become completely dry.
  • Check if all the tools and sufficient Hydro Ban® material is available for completion of job without any disturbance.
  • Cordon off the area and don’t allow any traffic after application of Hydro Ban®.

The following precautions are very important and critical while application of Hydro Ban®:

  • Check if the surface preparation is done thoroughly. Check all the details of differential elements like GI, PVC pipes coming through the substrate, ceramic fixtures to screed joints, concrete to brick masonry joints etc.
  • Apply Hydro Ban® on all the above differential element joints ensuring complete closure of the joints.
  • Do not apply Hydro Ban® on surfaces with moisture or looking wet. Hydro Ban® must be applied only on completely dry surfaces.
  • If the temperature is too low (Below 12 Degrees Centigrade), use heaters to increase the temperature while installing Hydro Ban®. If the temperature is too high (more than 35 Degrees Centigrade), work during the evening / night / early morning to get best results.
  • Don’t use putty blades for application of Hydro Ban® One can use a flat side of trowel for application of Hydro Ban®
  • Don’t allow any other works like plumbing, electrical fittings, plastering, tiling or painting to be done in the water proofing area while applying the Hydro Ban®. Don’t allow any traffic other than people who are working with Hydro Ban® membrane.
  • Do not apply Hydro Ban® if there are joints in substrate which are more than 3 mm width. In case the joints of substrate are more than 3 mm in width, use fabric roll over the joints before application of Hydro Ban®.
  • Always use fresh and clean roller/brush/trowel for application of Hydro Ban®.

Foot traffic is allowed after 24 hours from the completion of second coat of the LATICRETE® 9237. Make sure people don’t wear spiked shoes or any tools which can puncture the membrane.

The application of Hydro Ban® must be done at total of 800 microns thickness in 2 coats of application. The best way to get this is to apply 20 Kg of Hydro Ban® on exactly 250 sq. ft. area. DO NOT APPLY IN HIGHER THICKNESSES AS Hydro Ban® may fail at thickness higher than 800 microns.

The biggest advantage of Hydro Ban® is its ability to stick to various materials like steel, PVC, GI, Copper besides concrete and plaster. Hence all the water bodies like bath rooms, swimming pools etc. which have such pipes and fixtures no special care (Fabric roll/silicone sealant) needs to be taken at joints which are a must with other water proofing membranes.Hydro Ban® has the ability to bridge future cracks in substrate with its excellent elongation of more than 400%. Tiles and stones can be installed directly on the cured membrane of Hydro Ban® with the help of adhesive.

Hydro Ban® can be used on the terraces and roof tops provided the membrane is covered with tiles using adhesive after the coating is completed. DO NOT USE Hydro Ban® IF THE AREA IS EXPOSED TO SUN LIGHT.

YES. Hydro Ban® is most suited for water proofing the dry wall boards in wet areas and wash rooms. One can install tiles /stones over the membrane directly using a polymer modified / fortified thin set adhesive.

YES. Hydro Ban® is a green building product and can contribute to the LEED points of the project.

Under normal temperature and humidity conditions one can do the flood testing of Hydro Ban® after 24 hours from the time of final coating. In areas where the temperature and humidity conditions vary, one can do the flood testing after 48 hours from the time of completion of the second coating.

No. It can be applied directly on all differential elements, joints of dry wall boards, other joints of width up to 3mm. In case of joints more than 3mm, fabric roll is necessary.

Full cure time of Hydro Ban® is 7 days.
